- BM-18R RADIUS MACHINE
BM-18R RADIUS MACHINE
NEW GENERATION OF POWERFUL, PORTABLE RADIUS MACHINES
The SteelBeast® BM-18R radius machine features a powerful pneumatic motor that creates an R2, R3, R4, or R5 Radius.
Want to make sure the 'BM-18R RADIUS MACHINE' is right for you? Speak to our specialist solutions team today.
FIND OUT MORE PURCHASE OR HIRE WATCH VIDEO
Rounding edges R2, R3, R4 or R5
Max bevel width 18 mm
Top bevelling
Bevel angles 22.5°, 30°, 37.5°, 45°, 50°, 55°, 60°
Countersinking Min. ID 40 mm
Min. plate thickness 2 mm
Why the BM-18R?
- Powerful 2200 W motor.
- Milling head for rounding is equipped with 4 pcs of 4-sided indexable inserts up to R5.
- Creates the perfect radius on both straight and curved edges.
- Maximum 18 mm bevel width (more than one pass could be required).
- New more durable milling heads with hexagonal fixing.
- Easy replacement of milling heads.
- Bevelling milling head is equipped with 5 pcs of 2-sided indexable cutting inserts.
- Bevel on holes from 40 mm in diameter.
New design of milling heads with hexagonal fixing
The BM-18R from SteelBeast offers increased durability and a more convenient way to assemble and disassemble the milling head.
The guiding roller is integrated neatly with each milling with the clearance between milling and guiding roller is precisely calibrated. Therefore, requires no adjustment by the operator.
FEATURES OF THE NEW BM-18R
Creating a perfect radius on both straight...
…and curved edges
Aluminum bevelling
Bevel on holes from 40 mm in diameter
Accessories
Air preparation unit ZST-000021
Cutting insert R5 (sold 10 pcs/box)
Cutting insert for steel (sold 10 pcs/box)
Cutting insert for aluminum (sold 10 pcs/box)
Radius insert positioner
Beveling milling head
